Radio Management

Configure radio using block and System object™ settings

Before transmitting and receiving radio signals, first apply radio hardware parameters and tune radio properties.

Functions

captureCapture RF data using SDRu receiver (Since R2023b)
setsdruipSet IP address for USRP radio
infoCurrent USRP radio settings
referenceLockedStatusLock status of USRP radio to 10 MHz clock signal (Since R2021a)
gpsLockedStatusLock status of GPSDO to GPS constellation (Since R2021a)
getRadioTimeGet current USRP radio time (Since R2023b)

Objects

comm.SDRuReceiverReceive data from USRP device
comm.SDRuTransmitter Send data to USRP device

Blocks

SDRu ReceiverReceive data from USRP device
SDRu TransmitterSend data to USRP device

Topics

Troubleshooting

Common Problems and Fixes

Describes the most common errors encountered with Communications Toolbox™ Support Package for USRP Radio and how to fix them.
