Distribute values from one table variable to multiple table variables in the Live Editor
The Unstack Table Variables task lets you interactively unstack, or distribute, values in a table or timetable from one variable to multiple variables. The task automatically generates MATLAB® code for your live script.
To add the Unstack Table Variables task to a live script in the MATLAB Editor:
On the Live Editor tab, select Task > Unstack Table Variables.
In a code block in the script, type a relevant keyword, such as
table. Select Unstack
Table Variables from the suggested command completions.
This example shows how to unstack values from one variable in an input table and distribute them to multiple variables in an output table by using the Unstack Table Variables Live Editor task.
First, load a table that contains estimated influenza rates along the east coast of the United States. The table has a variable with flu rates and another variable indicating whether the rates are for the Northeast (
NE), Mid-Atlantic (
MidAtl), or Southeast (
SE) regions. (These data come from the Google Flu Trends, https://www.google.org/flutrends.)
Add the Unstack Table Variables task to your live script. Unstack the
Flu Rate variable so that the output table has variables named
SE, containing flu rates for those regions.
To group the data by month, select the
Group by menu item below the
Month variable in the task.
To select the names of the output variables, click the radio button
Names of new columns above the
Region variable. For each unique value in
Region, there is a corresponding variable in the output table.
To distribute values from the
Flu Rate variable into the
SE variables in the output, click the radio button
Values in new columns above
