External mode logging uses specific code that Simulink®
PLC Coder™ generates. External mode logging can save system states,
outputs, and simulation time at each model execution time step. The data
is written to a MAT-file, named (by default)
model is the
name of your model. You can collect run-time data for the variables in
the MAT-file by running the generated code, which contains the logging
function in your target IDE.
Collect and visualize the output of the generated code as executed in the target PLC IDE by using external mode logging.
