Electrical Reference
Connection to electrical ground
Library
Electrical Elements
Description
The Electrical Reference block represents an electrical ground. Electrical conserving ports of all the blocks that are directly connected to ground must be connected to an Electrical Reference block. A model with electrical elements must contain at least one Electrical Reference block.
Ports
The block has one electrical conserving port.
Extended Capabilities
Version History
Introduced in R2007a
