Synchronize model execution to real time in Connected IO mode
Simulink Desktop Real-Time
Synchronize your Simulink® model with the real-time kernel clock at Real-Time Sync block sample hits. The parameters specify only sample time and missed tick values. There are no input ports.
The Real-Time Sync block operates only in Connected IO mode. It has no function in Run in Kernel mode.
If the Connected IO mode model contains another Simulink Desktop Real-Time™ block, the other block synchronizes the Simulink model with the real-time clock. Do not include the Real-Time Sync block in such a model.
