The Phased Array System Toolbox™ lets you graphically display RTI, DTI, and other time-dependent data.
|View angle-time array response (Since R2022b)|
|Angle-Doppler scope (Since R2019a)|
|Doppler-time intensity scope (Since R2019a)|
|Range-time-intensity (RTI) or Doppler-time-intensity (DTI) display|
|View range-angle response (Since R2019a)|
|Range-Doppler scope (Since R2019a)|
|Range intensity scope (Since R2019a)|
- Measure Intensity Levels Using the Intensity Scope
This tutorial shows you how to measure the intensity of signals using the UI of the intensity scope.
