Build Real-Time Application

Real-time application building and downloading

To run a real-time application on a target computer, set the model configuration parameters to values consistent with real-time execution. See Simulink Real-Time Options Pane. To drive the model, create inport data and then build and download the real-time application.

Tools

Simulink Real-Time ExplorerInteract with target computer and real-time application running on target computer
Simulink Real-Time TET MonitorMonitor task execution time for the real-time application running on target computer
Simulink Real-Time App GeneratorGenerate instrument panel app to interact with target computer and real-time application running on target computer
Simulation Data InspectorInspect and compare data and simulation results to validate and iterate model designs

Objects

ApplicationRepresent application files on development computer

Functions

slrtExplorerOpen Simulink Real-Time explorer and interact with target computers and real-time applications
slrtAppGeneratorGenerate instrument panel app to interact with target computer and real-time application running on target computer

Topics

Troubleshooting

Troubleshooting in Simulink Real-Time

Troubleshoot problems that you encounter while using the Simulink Real-Time product
