Import and Export Architecture Model

Import models from third-party tools and export them with System Composer changes

System Composer allows you to import an architectural model that was created in a third-party database or architecture modeling tool like Microsoft® Visio or Sparx Enterprise Architect, edit it, and export it back, including all of the changes. Build your custom import and export layers, create an architecture model, and export back the modified model.

Classes builder for System Composer architecture models


systemcomposer.importModelImport model information from MATLAB tables
systemcomposer.exportModelExport model information as MATLAB tables


Import and Export Architecture Models

Import and export information about your models.

Featured Examples
